conga-cWL6 Preview image

Your item has been added to the inquiry

conga-cWL6 Image

conga-cWL6

COM Express® Compact Type 6 with 8th Generation Intel® Core™ / Celeron® Processors

Selected product variant

    Selected ecosystem parts

    Cooling Solutions

      Value adding ecosystem offerings

      Cooling Solutions

      Request quote Add more articles

      conga-cWL6

      formerly JUMPtec COMe-cWL6

      COM Express® Compact  Type 6 with 8th Generation Intel® Core™ / Celeron® Processors

      Learn all about COMs - download the guide

      • 8th Generation Intel® Core™ / Celeron® Processors
      • Up to 48 GByte DDR4 memory (16 GByte DDR4 memory down)
      • Industrial grade versions
      Congatec Logo
      Do you want to add further ecosystem parts (carrier boards, memory,...) to your request?

      Value adding ecosystem offerings

      Cooling Solutions

      Specification

      Formfactor
      COM Express Compact
      CPU
      Intel® Core™ i7-8665UE – 4 x 1.7 GHz, 8MB cache, 15W
      Intel® Core™ i5-8365UE – 4 x 1.6 GHz, 6MB cache, 15W
      Intel® Core™ i3-8145UE – 2 x 2.2 GHz, 4MB cache, 15W
      Intel® Celeron® 4305UE – 2 x 2.0 GHz, 2MB cache, 15W
      DRAM
      1x DDR4 SO-DIMM up to 32 GByte, 2nd channel DDR4 memory down up to 16 GByte
      Ethernet
      10/100/1000 MBit Ethernet
      I/O Interfaces
      6 x 5x PCIe 3.0 (On request: 6x without Ethernet, up to 8x without Ethernet & SATA)
      1x4 PCIe 4.0 on PEG Lanes #0-3
      4x PCIE 3.0 on PEG Lanes #0-3
      4 x USB 3.1 (incl. USB 2.0)
      4 x USB 2.0
      2 x serial interface (RX/TX only)
      SPI
      LPC
      SMB
      Fast I²C
      RTC
      support of Intel® Optane™ memory technology via PCIe
      Mass storage
      2xSATA 6Gb/s
      Graphics
      Intel® UHD Graphics 620 (Celeron® 4305UE: Intel® UHD Graphics 610)
      embedded BIOS Features
      AMI Aptio V
      Security
      Trusted Platform Module (TPM 2.0)
      Power Management
      ACPI 6.0
      Operating Systems
      Windows®10
      Linux
      VxWorks
      Temperature
      0 °C to +60 °C operating, -30 °C to +85 °C non-operating
      industrial temperature: -40 °C to +85 °C operating, -40 °C to +85 °C non-operating
      Humidity
      93 % relative Humidity at 40 °C, non-condensing (according to IEC 60068-2-78)
      Video Interfaces
      2 x DP++
      LVDS: Dual Channel 18/24bit
      Features
      Staged Watchdog
      Size
      95 x 95 mm (3,74" x 3,74")

      Documents

      All documents found on this page are updated without notification. Always check this page for the latest version.

      Data Sheet
      Datasheet conga-cWL6 11.11.2026
      Manual
      User's Guide for conga-cWL6 06.05.2026
      Whitepaper
      The Computer-on-Modules Compendium Download for free and gain the ultimate reference guide to COM technology. From fundamentals to advanced use cases – this compendium helps you design faster, smarter, and more efficiently.

      Software

      Linux
      kempld-drivers.37.tar.gz 10.06.2026 / 3.44 Mo
      Linux PLD Board Driver for GPIO, I2C and Watchdog. Please follow the readme inside for driver usage and supported features. Note: The Kontron PLD driver is part of the stable Linux Kernel compatible with revision 3.11 or later. Supported hardware and features depend on the Kernel revision and may differ from the driver available here
      Windows 10
      README_WIN10_64_BSP_COME_CWL6 18.06.2026 / 58.42 Ko
      Readme Win10 BSP

      Product Variants

      partnumber(s) found

      conga-cWL6 i7-8665UE 8GB (P/N 36028-8000-17-7)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i7-8665UE, 4x1.7 GHz, 8GB memory down, DDR4 SO DIMM Socket

      conga-cWL6 i5-8365UE 4GB (P/N 36028-4000-16-5)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i5-8365UE, 4x1.6 GHz, 4GB memory down, DDR4 SO DIMM Socket

      conga-cWL6 i7-8665UE 16GB / 1TB (P/N 36028-1610-17-7)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i7-8665UE, 4x1.7 GHz, 16GB memory down, DDR4 SO DIMM Socket, 1024GB NVMe

      conga-cWL6 i3-8145UE (P/N 36028-0000-22-3)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i3-8145UE, 2x2.2 GHz, DDR4 SO DIMM Socket

      conga-cWL6 4305UE (P/N 36028-0000-20-2)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Celeron® 4305UE, 2x2.0 GHz, DDR4 SO DIMM Socket

      conga-cWL6 i3-8145UE E1 (P/N 36028-0000-22-3EXT)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i3-8145UE, 2x2.2 GHz, DDR4 SO DIMM Socket,extended temperature version

      conga-cWL6 4305UE E1 (P/N 36028-0000-20-2EXT)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel®Celeron® 4305UE, 2x2.0 GHz, DDR4 SO DIMM Socket, extended temperature version

      conga-cWL6 E2S i7-8665UE 8GB (P/N 36028-8000-17-7)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i7-8665UE, 4x1.7 GHz, 8GB memory down, DDR4 SO DIMM Socket, industrialtemperature grade

      conga-cWL6 E2S i5-8365UE 4GB (P/N 36029-4000-16-5)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i5-8365UE, 4x1.6 GHz, 4GB memory down, DDR4 SO DIMM Socket, industrialtemperature grade

      conga-cWL6 i3-8145UE (P/N 36029-0000-22-3)

      COM Express® compact pin-out type 6 Computer-on-Module with Intel® Core™i3-8145UE, 2x2.2 GHz, DDR4 SO DIMM Socket, industrial temperature grade

      Ecosystem Details

      Cooling Solutions

      HSP COMe-cWL6 Cu-core threaded (P/N 36028-0000-99-0)

      Heatspreader for COMe-cWL6, Cu-core, threaded mounting holes

      HSP COMe-cWL6 Cu-core through (P/N 36028-0000-99-1)

      Heatspreader for COMe-cWL6, Cu-core, through mounting holes
